SCPb
Manufacturer: Schmalz (J. Schmalz GmbH)
Compact ejector, pure-pneumatic
The SCPb is a purely pneumatic compact ejector designed for energy-efficient vacuum generation, suitable for handling airtight and slightly porous workpieces. It operates without electronic components and features an integrated air-saving function that reduces compressed air consumption by up to 80%.
Price: Price $1,186.92-$1,513.50 (7 priced variants)
Specifications
- Suction Rate
- 75 to 185 l/min
- Max Vacuum
- 85%
- Air Consumption (Suction)
- 115 to 290 l/min
- Sound Pressure Level
- 76 to 77 dB(A)
- Operating Pressure Range
- 4.0 to 7.0 bar
- Max Vacuum (mbar)
- -850 mbar
- Control Valve
- Normally open
- Switch-on Value Regulation
- -630 mbar
- Nozzle Size
- 1.5 to 2.5 mm
- Protection Type
- IP 65 (with plug)
- Material
- High strength plastic
